Description
| PRODUCT SPECIFICATIONS | |
| Anti-vibration | ISO 16752-3:2012 (5.9G) |
| Detection Distance | Front/Side: 0.5-30m (H) | Rear: 0.5-20m (H) |
| Power Supply | DC 10-32V |
| Current Draw (12V) | 150mA (IR off) | 700mA (IR on) |
| Frame Rate | 25 / 30 fps |
| Output Signal | AHD (1.0 Vp-p, 75Ω) |
| Resolution | 2688 x 1944 (ADA32N) | 1920 x 1080 (ADA32) |
| Viewing Angle | Front & Rear view 130° (H) |
| Audio Output | Warning sound signal output |
| Interface | USB 2.0 (software upgrade) |
| Cable Length | 3m |
| Operating Temp | -20°C to +70°C |
| Storage Temp | -30°C to +80°C |
| Waterproof Rating | IP69K |
| Dimensions | 95 x 60 x 70 mm |
| Weight | 500 g |
| Housing Colour | Black |
| Output Mode | CVBS/Fast Ethernet (ADA32N) AHD/CVBS/Fast Ethernet (ADA32) |
| Network Protocol | RTSP/ISO17215 |
