Description
PRODUCT SPECIFICATIONS
| Sensor | 1/3” Colour CMOS |
| TV Lines | 650TVL |
| Effective Pixels | 756(H) x 504(V) |
| TV System | NTSC (PAL Optional) |
| Viewing Angle | 130° |
| Lens | 2.1mm |
| White Balance | Automatic |
| Infra-Red LED’s | Yes (5 x IR’s) |
| Protection Rating | IP67 |
| Operating Temperature | –20°C to +50°C |
| Operating Voltage | 12VDC |
| Current Consumption | 110mA |
| Dimensions (w x H x D) mm | 92 x 40 x 40.7 (camera only) |
| Package Contents | Camera, Heavy Duty Bracket, Screws, Installation Manual |
