Description
PRODUCT SPECIFICATIONS
| Sensor | 1/4” CCD |
| Resolution | 600TVL |
| TV System | PAL |
| Viewing Angle | 126° diagonal (optional 45° diagonal) |
| Lens Focal Length | 2.6 mm (optional 8mm lens) |
| Minimum Illumination | 0 Lux |
| White Balance | Yes, Automatic |
| Infra-Red LED’s | Yes, 18 (10-12m distance) |
| Microphone | Yes |
| Protection Rating | IP68 |
| Operating Temperature | –30°C ~ +65°C |
| Operating Voltage | 12VDC |
| Power Consumption | 2W (200mA) max |
| Dimensions (H x W x D) mm | 82 x 73 x 58 |
| Casing Material | Aluminium |
| Connector | 4-pin mini DIN Male Screw Waterproof |
| Package Contents | Camera, Fixing Bracket, Screw Kit |
